Potentiostat Sensor Interface with NFC Forum Type 2 Tag IC – SIC4341
USD 3.9255
Type: QFN 0.85 mm
Packing: ESD bag
PCODE: P40CVQK4P20UT4110C2
Minimum Order Quantity: 20 psc
Shipping: Approximately 30-45 days From Silicon Craft Technology, Bangkok, Thailand
Please note: This product is sold in minimum order quantities. Orders must meet the required MOQ to proceed. For bulk order, please direct contact us.
500 in stock
SIC4341
Potentiostat Sensor Interface Chip
DOWNLOAD FACTSHEET
SIC4341 is a 236-byte NFC tag IC with potentiostat analog front-end and built-in ADC. The SIC4341 consists of an RF Analog-Front-End circuit supporting ISO/IEC 14443 A, a selectable 6-to-16-bit resolution sigma-delta ADC, an on-chip regulator, two 8-bit DACs, a potentiostat analog frontend circuit, a transimpedance amplifier, a voltage reference, a control register page and an EEPROM. SIC4341 is designed to perform voltametric techniques across 2/3-electrode chemical sensor and measure reaction current that generate by electrochemical cells.
Highlight Features
- Built-In Potentiostat AFE
- Sensor Electrode Channel
- Selectable 2/3 Electrode System
- Configurable Electrode Channel
- Data Streaming Controlled from NFC Mobile App
- Sensor Electrode Channel
- 1.28 V Internal Voltage Reference
- Built-In ADC, TIA
- Two 8-bit DACs for WE/RE Biasing
- Memory: 144 Bytes User Memory EEPROM
| Product Attributes | Description |
|---|---|
| Specification | SIC4341 |
| RFID Features | |
| Working Principle | Chip excites sensor with potential and induce electrochemical reaction to occur, then measures the changes in sensor through current. |
| Communication Interface | NFC Forum Type 2 Tag ISO/IEC 14443 A |
| Power Management | RF On-chip regulator 1.9 V |
| Number of Channels | 3 I/O Configurable WE, RE, CE |
| Voltage Source | |
| Bias Wave Form | DC |
| Bias Voltage Range, Resolution | V(WE-RE) -0.8 V to +0.8 V, 5mV/step |
| Bias Voltage Accuracy | ± 6 mV |
| Compliance Voltage | -1.3V to +1.4V |
| Analog Input | |
| Measured Current Range | Selectable ± 2.5 uA ± 20 uA |
| Measured Accuracy | ± 5 nA for ± 2.5 uA ± 20 nA for ± 20 uA |
| Data Conversion Rate | 10 sps |
| Memory | |
| User Memory | 144 bytes |
| Erase/Write Cycles | 100,000 times |
| Data Retention | 10 years at 70°C |
| Others | |
| Compatible Analysis Techniques | Amperometry, Voltammetry |
| Available Form Factors | QFN 3×3 – 16 leads, Sawn Wafer with Bump |
Applications
|
|
DEVELOPMENT KIT
SUPPORT MATERIALS
- Demonstration Software : iOS, Android application
- Reference PCB design and schematic diagram
- Reference antenna design
